Bearing Assy

🔧 CFMoto Bearing Assembly (Spherical Bearing)

📦 Part Number: 7020-051610-30000

⚙️ Spherical Plain Bearing Assembly · OEM Specification

📍 Installation Position: Suspension System / Steering Linkage / Rod Ends

✅ Self-Lubricating · Impact Resistant · Fits Multiple CFMoto ATV/SSV/UTV Models

This product is a CFMoto OEM-spec bearing assembly (spherical plain bearing assembly), part number 7020-051610-30000. A spherical plain bearing features a spherical inner ring that allows angular misalignment and oscillation while supporting radial loads. These bearings are widely used in suspension systems, steering linkages, control arms, and other connections requiring both rotational and pivoting movement.

Over time, spherical bearings may experience wear, increased clearance, corrosion, or seizure, leading to suspension noise, loose steering, and incorrect wheel alignment. Timely replacement of worn bearings is essential to restore vehicle handling stability and ensure driving safety.

• ✅ OEM Specification: Manufactured strictly to CFMoto original technical standards; dimensions and spherical fit tolerances are identical to the original part.
• 🛡️ Self-Lubricating Design: Embedded self-lubricating liner eliminates the need for additional grease; maintenance-free operation.
• 💪 High-Strength Material: Alloy steel outer ring with hardened inner ring provides excellent wear resistance and impact strength.
• 🔧 Wide Angular Movement: Allows significant angular misalignment and oscillation compensation for demanding off-road suspension travel.
• 🔄 Direct Replacement: Directly replaces worn, loose, or corroded original bearings.
• 🚗 Restores Handling: Effectively eliminates suspension noise and loose steering, restoring vehicle stability.

✅ Signs Your Bearing Assembly Needs Replacement:
• Clunking or knocking noise from the suspension when driving over bumps.
• Loose steering feel, excessive play, or poor directional stability.
• Uneven tire wear (alignment issues).
• Damaged dust boot, visible corrosion, or excessive bearing clearance.
• Bearing clearance exceeds specification during inspection.
If any of these symptoms occur, please inspect and replace the bearing assembly promptly.

✅ Installation Tips:
1. Clean the mounting bore thoroughly before installation, removing rust and debris.
2. Inspect the mounting bore for deformation or wear; repair or replace if necessary.
3. Use a proper press tool to install the bearing into the bore; avoid hammering to prevent damage.
4. Ensure the bearing is fully seated and the retaining ring or clip is securely fastened.
5. After installation, check that the bearing moves freely without binding or excessive play.
6. Replace bearings on both left and right sides simultaneously to maintain handling balance.
Professional installation is recommended.

⚠️ Important Notice: This product is a CFMoto bearing assembly (spherical plain bearing), part number 7020-051610-30000. Fits the CFMoto ATV, SSV, and UTV models listed above. Minor differences may exist between production batches. If your specific model is not listed, please contact customer service with your VIN for compatibility confirmation. Images are for reference only; actual product may vary.
