Bolt M51.016

Brand: Mortch Motor
Product Code: MICF0010-030002-00001

Product Viewed: 63

Availability: In Stock

Weight: 0.01kg

0 reviews / Write a review

US$0.15

Shipping To：

More Quotes

CFMoto Bolt M5×1.0×16

OEM: 0010-030002-0020 / 0010-030002-00001 / 0010-030002-0010 / 1F30-063001

Fits CFMoto 400cc / 500cc / 600cc / 800cc / 1000cc models

📋 Product Overview

This is an OEM-quality CFMoto hex bolt, specification M5×1.0×16mm. It fits various CFMoto ATV, UTV, and SSV models for engine, frame, and component fastening. Manufactured from high-strength steel with precision thread rolling and surface treatment, offering excellent tensile strength and corrosion resistance.

Compatible with multiple OEM part numbers: 0010-030002-0020, 0010-030002-00001, 0010-030002-0010, and 1F30-063001 — a versatile fastener suitable for various applications.

✨ OEM Quality: Manufactured strictly to CFMoto factory specifications. Thread accuracy and mechanical strength are identical to genuine parts, ensuring perfect fitment and reliable fastening.

📐 Specifications

Thread Size M5

Pitch 1.0mm

Length 16mm

Material High-Strength Carbon Steel

Surface Finish Zinc Plated / Rust Protection

Part Numbers 0010-030002-0020 / 0010-030002-00001 / 0010-030002-0010 / 1F30-063001

🔧 Compatible Models (by Displacement)

🏍️ 400cc Series (191Q / 191Q-H Engine)

CF400ATR / CF400ATR-2L / -2S / -3L / -3S / -4L / -4S / -L / -5L / -5S (CForce 450 Series)
CF400AU / CF400AU-3L / -3S / -6S / -A / -B / -G / -L / -LF / -SF (CForce 400/450 Series)
CF400AZ-3L / -3S / -6L / -6S (CForce 400/450 Series)
GOES TERROX 400L / 400S
IRON MAX T3 / IRON T3 (L7e)
CForce 400 Classic / Touring

🏍️ 500/550cc Series (191R / 191R-C / 191R-E / 191R-X550 / 191R-Z550 / 191R-U550 Engine)

CF500ATR / CF500ATR-2L / -2S / -3 / -9L / -9S / -11L / -11S / -15L / -17L / -A / -2LC / -2SC / -5L / -5S (CForce 520/550 Series)
CF500AU-6B / -6L / -7A / -7C / -7L / -7S / -8L / -8S / -9S / -9L / -10S / -7LA / -7SA / -9SH (CForce 500/520/550 Series)
CF500AZ-9S / -10S (CForce 500/520 Series)
CF500US / CF500UTR / CF500UU (ZForce / UForce 500/550 Series)
COBALT / COBALT MAX Series
GOES TERROX 500L / 500S

🏍️ 600/625cc Series (191S / 191S-A / 191S-B / 191S-U6 Engine)

CF600ATR-2L / -2LC / -2S / -2SC / -L (CForce 600/625 Series)
CF600AU-3L / -3LA / -3LF / -3LH / -3S / -3SA / -3SF / -L / -3SH (CForce 600/625 Touring Series)
CF600AZ-3L / -3LA / -3S / -3SA (CForce 600 Series)
CF600UTR / CF600UU / CF600UZ (UForce 600 Series)

🏍️ 800/850cc Series (2V91W / 2V91W-A / 2V91W-B / 2V91W-D / 2V91W-F / 2V91W-G / 2V91W-K / 2V91W-S Engine)

CF800-2 / CF800ATR / CF800ATR-2 / -3 / -5 (CForce 800/850 Series)
CF800AU-2A / -2AF / -2B / -3 (CForce 800XC/850XC Series)
CF800AZ-2A / -3 (CForce 800/850 Touring Series)
CF800 / CF800US / CF800UTR / CF800UU / CF800UZ / CF800SU / CF800SZ (ZForce / UForce 800 Series)
X8 / Z8 / U8 Series

🏍️ 1000cc Series (2V91Y / 2V91Y-C / 2V91Y-D / 2V91Y-F / 2V91Y-U10 / 2V91Y-X10 / 2V91Y-Z10 Engine)

CF1000ATR / CF1000AU / CF1000AZ / CF1000ATR-2 / -2A / -3 / -3L / -4L (CForce 1000 Series)
CF1000US / CF1000US-2 / CF1000UTR-2 / -3 / -5 / -6 / -B / -C (ZForce 1000 Series)
CF1000UU / CF1000UZ / CM1000UZ (UForce 1000 Series)
CF1000SU / CF1000SZ / CF1000STR (ZForce 950/1000 Sport / Trail / Crew Series)
X10 / Z10 / U10 Series

📌 Compatibility Note: This bolt fits all CFMoto model series listed above, covering 400cc to 1000cc displacement. The list above summarizes representative models — actual applications are broader. All country/region code variants (such as T3a, T3b, HLG, KSR, SS, GD, AU, CA, US, etc.) are compatible. As a standard fastener, it can be used as long as the specifications match.

⚙️ Features

OEM Part Number Compatibility: Compatible with multiple OEM numbers: 0010-030002-0020, 0010-030002-00001, 0010-030002-0010, 1F30-063001.
Precision Thread: Rolled thread process for high accuracy, strength, and smooth engagement.
High-Strength Material: Manufactured from high-quality carbon steel with strength grade meeting OEM requirements for reliable fastening.
Rust Protection: Zinc-plated surface provides excellent corrosion resistance.
Versatile: M5×1.0×16mm standard size suitable for engine, frame, body panel, and various fastening applications.

✅ Service Tip: When replacing bolts, verify thread size and length match the original. Use a torque wrench to tighten to specified torque — avoid overtightening which may damage threads or undertightening which may cause loosening. For critical applications, replace spring washers or apply thread locker simultaneously.

⚠️ Installation Note: Before installation, clean the bolt hole to ensure no oil or debris. Hand-start the first few threads to confirm smooth engagement before tightening with tools. Do not use impact wrenches directly on small bolts to avoid thread damage.

📑 Part Information Summary:

Bolt: CFMoto 0010-030002-0020 / 0010-030002-00001 / 0010-030002-0010 / 1F30-063001
Specifications: M5 × 1.0 × 16mm
Material: High-Strength Carbon Steel / Surface: Zinc Plated

This bolt fits multiple CFMoto models — a standard fastener commonly used in daily maintenance and repair, providing OEM-quality reliable fastening performance.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
