Magneto Stator Assy

🔧 CFMoto Magneto Stator Assembly

📦 Part Number: 0JWV-032000-3200

⚙️ Magneto Stator · Charging Coil Assembly · OEM Specification

📍 Installation Position: Left Side of Engine / Inside Magneto Cover / Inside Flywheel

✅ Precision Wound · High Quality Enameled Wire · Suitable for CFMoto Specified Models

This product is a CFMoto OEM specification magneto stator assembly, part number 0JWV-032000-3200. The magneto stator is a core component of the engine charging system and ignition system. It works in conjunction with the flywheel rotor to generate alternating current (AC) while the engine is running, charging the battery and powering the vehicle's electrical equipment, while also providing trigger signals for the ignition system. Manufactured with high-quality silicon steel laminations for the core and high-strength enameled copper wire for precision windings, it offers excellent electromagnetic performance and insulation properties.

Over time, the stator assembly may experience burned coils, short circuits, open circuits, or insulation aging, leading to charging system failure, battery discharge, difficulty starting the engine, or even complete engine failure. Timely replacement of a damaged stator assembly is critical to ensuring normal engine operation and electrical system stability.

• ✅ OEM Original Specification: Manufactured strictly to CFMoto original technical standards. Coil parameters match original parts completely.
• 🛡️ High Quality Silicon Steel Core: Made with low iron loss, high permeability silicon steel laminations for high electromagnetic conversion efficiency.
• 🔧 Precision Wound Coils: Wound with high-strength enameled copper wire for uniform, tight windings and good insulation.
• 💪 High Temperature Insulation Treatment: Coils are vacuum impregnated for high temperature, oil, and vibration resistance.
• 🔄 Direct Replacement: Directly replaces burned, shorted, or aged original stator assemblies.

✅ Typical Signs That Stator Assembly Replacement Is Needed:
• Frequent battery discharge; charging system fails to charge properly.
• Difficulty starting the engine or intermittent engine operation.
• Charging indicator light stays on or flashes.
• Multimeter measurements show stator coil resistance values out of specification (open circuit, short circuit).
• Visible burning, discoloration, or insulation peeling on the stator coil.
If you experience any of these symptoms, please inspect and replace the stator assembly promptly.

✅ Installation Tips:
1. Disconnect the negative battery cable before replacing the stator.
2. When removing the magneto cover, take care not to damage the gasket or O-ring.
3. When installing the new stator, tighten the mounting bolts to OEM torque specifications.
4. Check the clearance between the stator coil and flywheel magnets to ensure no interference.
5. After installation, start the engine and measure the charging voltage with a multimeter to verify proper charging system operation.
6. It is recommended to also check the flywheel magnets for looseness or damage.
Professional installation by a qualified technician is recommended.

⚠️ Important Notice: This product is a CFMoto magneto stator assembly, part number 0JWV-032000-3200. Suitable for the CFMoto ATV and UTV models listed above. Minor variations may exist between production batches. If your specific model is not listed, please contact us with your VIN for compatibility verification. Images are for reference only; actual product may vary.
