Throttle Body

Brand: Mortch Motor
Product Code: MICF0GQ0-173000-20000

Product Viewed: 3

Availability: In Stock

Weight: 0.45kg

0 reviews / Write a review

US$205.64

Shipping To：

More Quotes

🔧 CFMoto Throttle Body Assembly

📦 Part Number: 0GQ0-173000-20000

⚙️ Throttle Body Assembly · Throttle Valve Unit · OEM Spec

📍 Installation Location: Engine intake system / Between air filter and intake manifold

✅ Single unit · Precision aluminum casting · Direct fit · Compatible with multiple CFMoto ATV models

📋 Product Overview

This is a CFMoto OEM-spec Throttle Body Assembly, part number 0GQ0-173000-20000, sold as a single unit. The throttle body is a core component of the EFI engine intake system, installed between the air filter and the intake manifold. It regulates the amount of air entering the engine by controlling the throttle plate angle, working with the ECU to precisely control the air-fuel ratio — a critical component affecting engine power output, fuel economy, and emissions performance.

Over time, the original throttle body may suffer from throttle plate shaft wear, valve sealing issues, idle bypass passage clogging, or throttle position sensor (TPS) failure — resulting in unstable idle, sluggish acceleration, hard starting, or increased fuel consumption. Replacing with an OEM-spec throttle body is essential to restore engine performance.

✅ OEM Quality Assurance: Manufactured strictly to CFMoto original technical standards. Made from precision aluminum casting, with throttle plate diameter, shaft diameter, and sensor interfaces identical to the genuine part, ensuring a perfect replacement and reliable intake control performance.

📐 Specifications

🔖 Part Number: 0GQ0-173000-20000

🏷️ Product Name: Throttle Body Assembly

📦 Packaging: Single unit

📍 Installation: Between air filter and intake manifold

🧪 Material: Precision aluminum casting

⚙️ Function: Control intake air · Regulate air-fuel ratio

🚗 Vehicle Compatibility

This Throttle Body Assembly (part number 0GQ0-173000-20000, single unit) fits the following CFMoto ATV models:

🏍️ ATV 400/450 Series

CF400AU-LF · CForce 450L
CF400ATR-2L(T3a/T3b) · CForce 450L
CF400ATR-2S(T3a/T3b) · CForce 450S
CF400ATR-5L(T3b) · IRON MAX T3
CF400AU-A · CForce 450S
CF400AU-B · CForce 450L
CF400ATR-2L(T3b)(SS) · CForce 450L
CF400ATR-2S · CForce 450S
CF400ATR-2S(T3b) · CForce 450S
CF400ATR-3L(T3a/T3b) · CForce 450 L
CF400ATR-3L(T3b)(HLG/SS) · CForce 450L
CF400ATR-3S(T3b) · CForce 450S
CF400ATR-3S(T3b)(GD/HLG/SS) · CForce 450S
CF400ATR-4L · GOES TERROX 400L
CF400ATR-4L(SS) · GOES TERROX 400L
CF400ATR-4S · GOES TERROX 400S
CF400AU-SF · CForce 450S
CF400AU-3L · CForce 450L
CF400AU-3LH · CForce 450L
CF400AU-3S · CForce 450S
CF400AU-3S(GD/HLG) · CForce 450S
CF400AU-3SH · CForce 450S
CF400ATR-3L(T3a/T3b) · CForce 450 L
CF400ATR-3L(T3b)(HLG/SS) · CForce 450L
CF400ATR-3S(T3a/T3b) · CForce 450S
CF400AZ-3L · CForce 400 Touring/CForce 450 L
CF400AZ-3L(CA/RU/ST) · CForce 450 L
CF400AZ-3S · CForce 400/CForce 450
CF400AZ-3S(AU/CA/ST/US) · CForce 450S

🏍️ ATV 500/520 Series

CF500ATR-11L · GOES TERROX 500L
CF500ATR-11L(SS) · GOES TERROX 500L
CF500ATR-11S · GOES TERROX 500S
CF500AU-7A · CForce 520S
CF500AU-7C · CForce 520L
CF500AU-7L · CForce 520L
CF500AU-7S · CForce 520 S
CF500ATR-9L(T3b) · CForce 520 L
CF500ATR-9L(T3b)(GD/HLG/SS) · CForce 520 L
CF500AZ-9S · CForce 500S/CForce 520S
CF500AZ-9S(AU/CA/US) · CForce 500S/CForce 520S
CF500AU-8S · COBALT L7e
CF500AU-6B · CForce 550
CF500AU-7LF · CForce 520L
CF500AU-7SF · CForce 500S/CForce 520S
CF500ATR-9L(T3a) · CForce 520 L
CF500ATR-9S(T3a/T3b) · CForce 550 / 520S
CF500AU-9L · CForce 520 L
CF500AU-9L(GD/HLG/RU/ST) · CForce 520 L
CF500AU-9S · CForce 520S/CForce 500S
CF500AU-9S(GD) · CForce 520S
CF500ATR-9L(T3a/T3b) · CForce 520 L
CF500AU-9LH · CForce X5 520L
CF500ATR-2L(T3a/T3b) · CForce 520L
CF500ATR-2S(T3a/T3b) · CForce 520S
CF500ATR-3 · CForce 520 / 550

🏍️ ATV 600/625 Series

CF600ATR-2L(T3b) · CForce 625 Touring
CF600ATR-2S(T3b) · CForce 625
CF600ATR-L(T3a/T3b) · CForce 600
CF600AU-3L · CForce 600 Touring/625 Touring
CF600AU-3S · CForce 600/625
CF600AU-L(EU168) · CForce 600
CF600AU-3LF · CForce 600 Touring/625 Touring
CF600AU-3LF(GD/HLG) · CForce 600 Touring/625 Touring
CF600AU-3LH · CForce 600 Touring/625 Touring
CF600AU-3SF · CForce 625S EPS Touring
CF600AU-3SF(HLG) · CForce 625

📌 Fitment Note: This throttle body assembly fits the intake system of the listed CFMoto ATV models. Sold as a single unit. It is recommended to inspect the throttle body if you experience unstable idle, sluggish acceleration, or hard starting — replace if necessary. If your specific model is not listed, please contact us with your VIN to confirm compatibility.

⚙️ Product Features

✅ OEM Original Spec: Manufactured to CFMoto original technical standards; throttle plate diameter, shaft diameter, and sensor interfaces match the genuine part exactly.
🛡️ Precision Aluminum Casting: Made from high-quality aluminum alloy with precision casting for dimensional accuracy and long-term durability.
🔧 Direct Fitment: Connectors match the original perfectly — direct replacement with no modifications required.
💪 Precise Air Control: Throttle plate responds accurately for precise air-fuel ratio control with the ECU.
🔄 Direct Replacement: Replaces worn, sticking, or sensor-failed original throttle bodies.

✅ Typical signs you need to replace the Throttle Body:
• Engine idle is unstable — RPM fluctuates or stalls frequently.
• Sluggish acceleration — throttle response is delayed.
• Hard starting — both cold and hot starts are difficult.
• Fuel consumption increases noticeably with abnormal emissions.
• Throttle plate has visible carbon buildup, sticking, or shaft wear (visual inspection).
• Throttle position sensor (TPS) error codes are present.
If any of these occur, inspect and replace the throttle body promptly to restore normal engine performance.

✅ Installation Tips:
1. Confirm the throttle body is the correct 0GQ0-173000-20000 matching the original.
2. Disconnect the battery negative terminal for safety.
3. Remove the air filter assembly and intake duct to access the throttle body.
4. Disconnect the TPS and idle control valve wiring harness connectors.
5. Remove the throttle body mounting bolts and take out the old unit and gasket.
6. Clean the mounting surface and install the new gasket.
7. Install the new throttle body and torque mounting bolts to OEM specifications.
8. Reconnect the sensor connectors, reinstall the intake duct and air filter.
9. Reconnect the battery and perform throttle position learning (refer to service manual).
10. Start the engine and check idle and acceleration performance.
Installation requires mechanical and electronic knowledge; professional installation recommended. Throttle position learning is required after installation.

⚠️ Important Note: This product is a CFMoto Throttle Body Assembly, part number 0GQ0-173000-20000, sold as a single unit. Fits the listed CFMoto ATV models. Slight variations may occur between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may vary. After installation, be sure to perform throttle position learning (TPS reset) using diagnostic equipment to ensure the ECU correctly recognizes the throttle opening position.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
