Chain Upper Guide Rail Assy
- Brand: Mortch Motor
- Product Code: MICF0NYV-024500-1000
- Product Viewed: 38
- Availability: In Stock
- Weight: 0.06kg
US$5.50
| Shipping To： |
CFMoto Chain Upper Guide Rail Assy
Part Number: 0NYV-024500-1000
Product Type: Engine Timing System | Timing Chain Guide Rail Assembly
Fitment: CFMoto UForce 1000 PRO / PRO MAX / XL Series UTV
OEM-specification timing chain upper guide rail assembly, designed to guide and maintain proper tension and running path of the timing chain. Manufactured from high-strength wear-resistant material, ensuring precise valve timing operation and preventing chain jump or disengagement.
This product is a genuine quality CFMoto Timing Chain Upper Guide Rail Assembly, part number 0NYV-024500-1000. This guide rail is a critical component of the engine timing system, mounted in the upper position of the timing chain to guide the chain path, maintain proper tension, and reduce vibration and noise during chain operation.
The timing chain guide rail continuously withstands friction and impact from the chain during engine operation. Over time, it may experience wear, cracking, or failure. Timely replacement of worn guide rails is essential to ensure accurate valve timing, prevent chain jump or disengagement, and avoid severe engine damage.
🔧 Genuine Quality Assurance: Manufactured strictly according to CFMoto OEM technical standards using high-strength wear-resistant engineering plastic. Dimensions and mounting holes are identical to the original parts, ensuring perfect fitment and reliable durability.
Part Number:
0NYV-024500-1000
Product Type:
Timing Chain Upper Guide Rail Assembly
Material:
High-Strength Wear-Resistant Engineering Plastic
Engine Series:
380Y-3
- UTV CF1000UTR-8 UForce 1000 PRO (T1b) 380Y-3
- UTV CF1000UTR-8(GD) UForce 1000 PRO (T1b) 380Y-3
- UTV CF1000UTR-8K UForce 1000 PRO MAX (T1b) 380Y-3
- UTV CF1000UTR-8K(GD) UForce 1000 PRO MAX (T1b) 380Y-3
- UTV CF1000UTR-8K(HLG) UForce 1000 PRO MAX (T1b) 380Y-3
- UTV CF1000UTR-8L UForce 1000 PRO MAX (T1b) 380Y-3
- UTV CF1000UU-8 UForce 1000 XL 380Y-3
- UTV CF1000UU-8(AU) UForce 1000 PRO 380Y-3
- UTV CF1000UU-8(ST) UForce 1000 PRO 380Y-3
- UTV CF1000UU-8L U10 XL PRO 380Y-3
- UTV CF1000UU-8L(AU) U10 XL PRO 380Y-3
- UTV CF1000UU-8L(ST) U10 XL PRO 380Y-3
- UTV CF1000UU-8LK U10 XL PRO HIGHLAND 380Y-3
- UTV CF1000UU-8LK(AU) U10 XL PRO HIGHLAND 380Y-3
- UTV CF1000UU-8LK(RU) U10 XL PRO HIGHLAND 380Y-3
- UTV CF1000UU-8LK(ST) U10 XL PRO HIGHLAND 380Y-3
- UTV CF1000UU-8K UForce 1000 Pro Highland 380Y-3
- UTV CF1000UU-8K(AU) UForce 1000 Pro Highland 380Y-3
- UTV CF1000UU-8K(RU) UForce 1000 Pro Highland 380Y-3
- UTV CF1000UU-8K(ST) UForce 1000 Pro Highland 380Y-3
- UTV CF1000UZ-8 UForce U10 PRO 380Y-3
- UTV CF1000UZ-8(CA) UForce U10 PRO 380Y-3
- UTV CF1000UZ-8(US) UForce U10 PRO 380Y-3
- UTV CF1000UZ-8K UForce U10 PRO Highland 380Y-3
- UTV CF1000UZ-8K(CA) UForce U10 PRO Highland 380Y-3
- UTV CF1000UZ-8K(US) UForce U10 PRO Highland 380Y-3
- UTV CF1000UZ-8L UForce U10 PRO XL 380Y-3
- UTV CF1000UZ-8L(CA) UForce U10 PRO XL 380Y-3
- UTV CF1000UZ-8L(US) UForce U10 PRO XL 380Y-3
- UTV CF1000UZ-8LK UForce U10 PRO XL Highland 380Y-3
- UTV CF1000UZ-8LK(CA) UForce U10 PRO XL Highland 380Y-3
- UTV CF1000UZ-8LK(US) UForce U10 PRO XL Highland 380Y-3
📌 Fitment Note: This Timing Chain Upper Guide Rail Assembly (Part Number 0NYV-024500-1000) fits all CFMoto UForce 1000 PRO / PRO MAX / XL / U10 PRO Series UTV models listed above, with engine series 380Y-3. Regional variants (AU/CA/US/RU/ST/International) are included. If your specific model is not listed, please contact our customer service with your VIN for confirmation.
- Guides Chain Operation: The timing chain upper guide rail guides the chain along the correct path, ensuring precise synchronization between the crankshaft and camshaft.
- Reduces Vibration & Noise: The smooth, wear-resistant surface effectively reduces friction, vibration, and noise during chain operation, improving engine smoothness.
- Prevents Chain Jump: Maintains proper chain tension and stable trajectory, preventing chain slack, jump, or disengagement that could cause severe engine damage.
- Wear & Heat Resistant: Manufactured from high-strength wear-resistant engineering plastic, capable of withstanding high temperatures and prolonged friction inside the engine.
- OEM Replacement: Dimensions and mounting holes are identical to the original parts, allowing direct replacement of worn or damaged factory guide rails.
• Unusual engine noise (metal rubbing or chain slapping sound);
• Loose timing chain, potentially triggering check engine light;
• Reduced engine power, sluggish acceleration response;
• In severe cases, timing jump may occur, causing piston-to-valve interference and severe engine damage.
If you experience these symptoms, inspect and replace the timing chain guide rail assembly immediately.
- Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
- We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
- Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
- Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
- All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
- In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.
