Tension Plate

CFMoto Tension Plate

Part Number: 0NYV-024017-2000

🔧 Timing Tension Plate · Valve Train · Engine Internal

OEM quality · Wear-resistant material · Ensures smooth timing chain operation

This is a genuine CFMoto Tension Plate, part number 0NYV-024017-2000. The tension plate is an important component in the engine timing system (valve train), typically used in conjunction with the timing chain tensioner. It is installed on the slack side of the timing chain, providing a guide and sliding surface for the chain, and working together with the tensioner to maintain proper chain tension. The tension plate usually consists of a steel backing plate and a wear-resistant plastic/composite friction layer, designed to withstand continuous chain friction and impact. By replacing a worn original tension plate, the stability and reliability of the timing system are restored, preventing noise and timing misalignment caused by chain slack.

This Tension Plate fits the following CFMoto models:

• OEM Quality: Manufactured strictly to original specifications, ensuring mounting dimensions and friction surface curvature identical to the original part.
• Wear-Resistant Friction Layer: Made from high-strength, low-friction engineering plastic or composite material with excellent wear resistance and self-lubricating properties.
• Steel Backing Plate: Backing plate stamped from quality steel sheet, providing sufficient structural strength and rigidity for stable mounting.
• Precision Forming: Friction layer bonded securely to the backing plate with a smooth surface, reducing chain friction and operating noise.
• Direct Replacement: Perfect bolt-in fit when installed according to the factory service manual, restoring timing system performance.

🛑 Importance of Tension Plate

In timing chain engines, the tension plate plays a crucial role. It works together with the tensioner to provide proper tension and a running path for the timing chain. The friction layer of the tension plate is in direct contact with the high-speed chain, enduring continuous friction and impact. If the tension plate wears excessively, it can lead to insufficient chain tension and misalignment of the chain path, causing chain slap and vibration, resulting in noticeable noise. More seriously, chain vibration can lead to timing misalignment, causing piston-to-valve interference and severe engine damage. Therefore, during timing system service or overhaul, inspecting and replacing a worn tension plate is a necessary step to ensure long-term engine reliability. Timely replacement with a genuine-quality tension plate effectively extends timing system life and prevents costly engine repairs.

⚠️ Fitment Note: This product is Tension Plate (0NYV-024017-2000). It fits Z10 series SSV models with 380Y-2A engine. Before ordering, always verify your vehicle model and engine type. It is recommended to inspect the timing chain and tensioner condition when replacing this plate.
