Limit Bushing

🔧 CFMoto Limit Bushing

📦 Part Number: 0GRV-081007-5000

⚙️ Limit Bushing · Locating Bushing · OEM Spec

📍 Installation: Water pump assembly · Limiting/locating

✅ Single unit · Premium wear-resistant material · OEM specification · Fits multiple CFMoto ATV models

This is a CFMoto OEM-spec limit bushing, part number 0GRV-081007-5000, sold as a single unit. This bushing is a locating and limiting component within the water pump assembly, ensuring that rotating parts such as the pump shaft and impeller operate in the correct position, preventing axial movement and radial misalignment to maintain stable pump operation and sealing performance.

The limit bushing operates in a high-temperature, high-speed coolant environment and may suffer from wear, corrosion, or material aging — resulting in improper shaft positioning, impeller-to-housing contact, seal failure, or pump damage. Replacing it promptly with an OEM-spec bushing is essential to restore pump positioning accuracy and ensure proper cooling system operation.

• ✅ OEM Specification: Manufactured to CFMoto's original technical standards. Dimensions and tolerances are identical to genuine parts.
• 🛡️ Premium Wear-Resistant Material: Made from high-strength, wear-resistant, corrosion-resistant material for long-term reliability.
• 🔧 Precision Machining: Precision-machined internal/external diameters and faces for perfect fitment with the pump shaft and housing.
• 💪 Reliable Limiting: Effectively limits axial movement and radial misalignment of the pump shaft, ensuring stable pump operation.
• 🔄 Direct Replacement: Can be used to directly replace worn or damaged original limit bushings.

✅ Typical signs that the limit bushing needs replacement:
• Unusual vibration or wobbling from the water pump during operation.
• Axial or radial play detected in the pump shaft.
• Impeller rubbing against the housing, causing abnormal noise.
• Premature seal failure with coolant leakage.
• Inspection reveals bushing wear, deformation, or corrosion.
If any of these signs appear, please inspect and replace the limit bushing promptly.

✅ Installation Tips:
1. Confirm the bushing part number is 0GRV-081007-5000 and matches your vehicle.
2. Remove the water pump assembly and extract the old bushing.
3. Clean the bushing mounting bore, removing oil and debris.
4. Inspect the mounting bore for wear or damage.
5. Press the new bushing into the mounting bore, ensuring it is fully seated.
6. Check the clearance between the bushing inner diameter and the pump shaft.
7. Reassemble the pump and install it on the engine.
Professional installation is recommended. Pay attention to bushing orientation and position during installation.

⚠️ Important Notice: This product is a CFMoto limit bushing, part number 0GRV-081007-5000, single unit. Fits the listed CFMoto ATV models. Minor variations may exist between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may differ slightly.
