Front Output Shaft Assy

🔧 CFMoto Front Output Shaft Assembly

📦 Part Number: 0JWA-062300-10001

⚙️ Front Output Shaft Assembly · Driveline · OEM Spec

📍 Installation: Front differential/transfer case output

✅ Single unit · Premium alloy steel · Includes seals and bearing · Fits multiple CFMoto ATV/SSV/UTV models

This is a CFMoto OEM-spec front output shaft assembly, part number 0JWA-062300-10001, sold as a single unit. This assembly is a critical component of the 4WD driveline system, installed at the front differential or transfer case output, responsible for transferring power to the front wheel drive system.

The assembly includes the front output shaft, bearing, oil seal, O-ring, and bearing retainer — a complete set of parts for front output shaft service and replacement. The front output shaft is subjected to high torque and impact loads. Over time, it may suffer from wear, fatigue, or seal failure — resulting in abnormal noise, oil leakage, or loss of power transmission. Replacing it promptly with an OEM-spec assembly is essential to restore 4WD system performance and ensure driving safety.

• ✅ OEM Specification: Manufactured to CFMoto's original technical standards. Dimensions and mounting interfaces are identical to genuine parts.
• 🛡️ Complete Assembly: Includes front output shaft, bearing, oil seal, O-ring, and retainer — all essential parts in one package.
• 🔧 Premium Alloy Steel: Made from high-strength alloy steel with heat treatment and precision machining for excellent torsional and fatigue resistance.
• 💪 Reliable Transmission: Ensures stable and reliable 4WD power delivery, improving traction and handling.
• 🔄 Direct Replacement: Can be used to directly replace worn, damaged, or seal-failed original front output shaft assemblies.

✅ Typical signs that the front output shaft assembly needs replacement:
• Unusual noise (humming or clicking) from the front driveline.
• Oil leakage from the front differential/transfer case output area.
• 4WD power transmission is interrupted or slipping.
• Excessive play or axial movement in the front output shaft.
• Inspection reveals shaft wear, bearing damage, or seal failure.
If any of these signs appear, please inspect and replace the front output shaft assembly promptly.

✅ Installation Tips:
1. Confirm the assembly part number is 0JWA-062300-10001 and matches your vehicle.
2. Remove the front differential/transfer case output components.
3. Clean the mounting area and inspect the bearing housing and sealing surfaces.
4. When installing the new assembly, pay attention to the orientation of oil seal and O-ring.
5. Torque all mounting bolts to specification.
6. Check that the output shaft rotates smoothly with no binding.
7. Fill with appropriate gear oil and check for leaks.
Professional installation is recommended. Maintain cleanliness to prevent contaminants from entering the driveline.

⚠️ Important Notice: This product is a CFMoto front output shaft assembly, part number 0JWA-062300-10001, single unit. Fits the listed CFMoto ATV/SSV/UTV models. Minor variations may exist between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may differ slightly.
