Drive & Driven Bevel Gear Comp

Brand: Mortch Motor
Product Code: MICF0800-0622B0-00001

Product Viewed: 3

Availability: In Stock

Weight: 1.06kg

Packing Size: 12.00 x 12.00 x 6.00cm

0 reviews / Write a review

US$61.41

Shipping To：

More Quotes

🔧 CFMoto Drive & Driven Bevel Gear Assembly

📦 Part Number: 0800-0622B0-00001

⚙️ Drive & Driven Bevel Gear Set · Differential Gear Set · OEM Spec

📍 Installation: Front/Rear differential · Driveline

✅ Single unit · Premium alloy steel · OEM specification · Fits multiple CFMoto ATV/SSV/UTV models

📋 Product Overview

This is a CFMoto OEM-spec drive and driven bevel gear assembly, part number 0800-0622B0-00001, sold as a single unit. This assembly is the core transmission component of the differential, consisting of the drive pinion (driving bevel gear) and ring gear (driven bevel gear). It transfers power from the driveshaft to the axle shafts, enabling power direction change and torque distribution.

The bevel gear assembly is subjected to high torque and impact loads. Over time, it may suffer from tooth wear, pitting, chipping, or noise due to wear, fatigue, or poor lubrication — affecting differential operation and potentially causing driveline failure. Replacing it promptly with an OEM-spec assembly is essential to restore driveline performance and ensure driving safety.

✅ OEM Quality Assurance: Manufactured to CFMoto's original technical standards using premium alloy steel with precision machining and heat treatment. Tooth profile accuracy and meshing performance are identical to genuine parts, ensuring a perfect replacement and reliable transmission performance.

📐 Specifications

🔖 Part Number: 0800-0622B0-00001

🏷️ Product Name: Bevel Gear Assembly

📦 Package: Single unit

📍 Installation: Front/Rear differential

🧪 Material: Premium alloy steel

⚙️ Function: Power direction change · Torque distribution

🚗 Fitment

This bevel gear assembly (part number 0800-0622B0-00001, single unit) fits the following CFMoto models:

🏍️ CF800 Dedicated Platform

CF800ATR-2 · CForce 820LE (2016-2019) · 2V91W FOR CF800ATR-2
CF800UTR · ZForce Z8-EX (2017-2020) · 2V91W FOR CF800UTR
CF800UTR-2 · UForce 800 (2017-2022) · 2V91W FOR CF800UTR-2

🚙 UForce 800 (2V91W-U8)

CF800-3 · UForce 800 (2012-2022)
CF800UU-A · UForce 800 (2014-2025)

🏍️ Terralander 800 X8 / CForce 800 (2V91W-X8)

CF800-2 · Terralander 800 X8 (2011-2019)
CF800ATR · CForce 800 (2016)

🏎️ ZForce 800EX / Trail (2V91W-Z8)

CF800 · ZForce 800EX (2012-2022)
CF800US-A · ZForce 800 Trail (2013-2022)

🏍️ CForce 800XC / 850XC (2V91W-A)

CF800ATR-3 · CForce 850XC (2017-2025)
CF800AU-2A · CForce 850XC (2017-2025)
CF800AZ-2A · CForce 800XC (2022-2024)

🏍️ CForce 800XC / 850XC (2V91W-D)

CF800AU-2AF · CForce 800XC / CForce 850XC (2021-2025)

🏎️ ZForce 800 Sport (2V91W-G)

CF800SU-3 · ZForce 800 Sport (2025-2026)

🏍️ CForce 1000 Overland (2V91Y-C)

CF1000AU-F · CForce 1000 Overland (2020-2025)
CF1000AZ · CForce 1000 Overland (2023-2024)

🏎️ ZForce 950 / 1000 (2V91Y-D)

CF1000SU-3 · ZForce 950 Trail (2023-2025)
CF1000SU-3A · ZForce 950 Sport (2023-2024)
CF1000SU-3L · ZForce 950 Sport-4 (2024-2025)
CF1000SU-D · ZForce 950 H.O.EX / ZForce 1000 Sport R (2022-2025)
CF1000SU-E · ZForce 950 H.O.Sport (2022-2024)
CF1000SZ-3L · ZForce 950 Sport 4 (2023-2026)
CF1000SZ-D · ZForce 950 HO EX (2022-2025)
CF1000SZ-E · ZForce 950 HO Sport (2022-2023)
CF1000UTR-C · ZForce 1000 Sport R (2022-2025)
CF1000US-J · ZForce 1000 (Police) (2021-2022)

🚙 UForce 1000 (2V91Y-U10)

CF1000UTR-3 · UForce 1000 (2018-2026)
CF1000UTR-5 · UForce 1000 XL (2022-2026)
CF1000UU · UForce 1000 (2018-2025)
CF1000UU-2 · UForce 1000 XL (2022-2025)
CF1000UZ · UForce 1000 (2022-2026)
CF1000UZ-2 · UForce 1000 XL (2022-2026)
CF1000UZ-2A · UForce 1000 XL (2024)
CF1000UZ-A · UForce 1000 (2024)
CF1000YM-2J · UForce 1000 XL (2025)
CM1000UZ-2A · UForce 1000 XL Alpine (2024)
CM1000UZ-A · UForce 1000 Alpine (2024-2025)

🏍️ CForce 1000 (2V91Y-X10)

CF1000ATR · CForce 1000 (2018-2024)
CF1000AU · CForce 1000 EPS Overland (2018-2025)

🏎️ ZForce 1000 Sport / EX (2V91Y-Z10)

CF1000US · ZForce 1000EX (2020-2022)
CF1000US-A · ZForce 950 Sport / ZForce 1000 Sport (2020-2022)
CF1000UTR-B · ZForce 1000 Sport (2020-2022)

🏎️ ZForce 1000 (2V91Y-Z1000)

CF1000US-2 · ZForce 1000 (2016-2021)
CF1000UTR-2 · ZForce 1000 (2017-2021)

📌 Fitment Note: This bevel gear assembly is designed for the front/rear differential on the listed CFMoto ATV/SSV/UTV models. Single unit. If your specific model is not listed, please contact us with your VIN to confirm compatibility.

⚙️ Features

✅ OEM Specification: Manufactured to CFMoto's original technical standards. Tooth profile accuracy and meshing performance are identical to genuine parts.
🛡️ Premium Alloy Steel: Made from high-strength alloy steel with case-hardening heat treatment and precision grinding for excellent wear and fatigue resistance.
🔧 Precision Machining: Precision-ground gear teeth ensure perfect meshing with the mating gear for smooth and quiet operation.
💪 Reliable Transmission: Effectively transfers power and distributes torque, ensuring proper differential operation.
🔄 Direct Replacement: Can be used to directly replace worn, damaged, or noisy original bevel gear assemblies.

✅ Typical signs that the bevel gear assembly needs replacement:
• Unusual noise (humming, grinding, or whining) from the differential.
• Noise worsens during cornering.
• Metal particles found in the differential oil.
• Jerky or interrupted power transmission.
• Inspection reveals tooth wear, pitting, spalling, or broken teeth.
If any of these signs appear, please inspect and replace the bevel gear assembly promptly.

✅ Installation Tips:
1. Confirm the assembly part number is 0800-0622B0-00001 and matches your vehicle.
2. Remove the differential assembly and extract the old bevel gear set.
3. Clean the differential housing and inspect the bearings and housing condition.
4. Install the new bevel gear assembly, noting the meshing marks on the drive and driven gears.
5. Adjust gear backlash and bearing preload according to factory specifications.
6. Fill with appropriate differential oil.
7. Test drive and check for normal differential operation with no unusual noise.
Professional installation is recommended. Gear backlash and preload adjustment requires special tools and expertise.

⚠️ Important Notice: This product is a CFMoto bevel gear assembly, part number 0800-0622B0-00001, single unit. Fits the listed CFMoto ATV/SSV/UTV models. Minor variations may exist between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may differ slightly.
