C100 Drive Sprocket 14T

Brand: Mortch Motor
Product Code: MIC100-6041-14

Product Viewed: 194

Availability: In Stock

Weight: 0.09kg

Packing Size: 5.00 x 5.00 x 2.00cm

0 reviews / Write a review

US$1.30 448 SOLD

Shipping To：

More Quotes

C100 428 14 Teeth Steel Front Sprocket

🔗 Front Sprocket · Drive Sprocket · Countershaft Sprocket · Transmission Component

For Moped, Cub, Dirty Bike & ATV · Fits 139FMB, 147FMD, 147FMF, 150FMG engines

📋 Product Overview

This is the C100 428 14 Teeth Steel Front Sprocket, a critical component of the engine's drive system. It is suitable for Mopeds, Cub series, Dirty Bikes, and ATVs, and fits engines including 139FMB, 147FMD, 147FMF, 150FMG, and similar models.

The front sprocket (drive sprocket/countershaft sprocket) is mounted on the transmission output shaft and works with the rear sprocket and chain to transfer engine power to the rear wheel. Manufactured from high-strength steel with precision-machined and heat-treated teeth, it offers excellent wear resistance and impact strength. The 428 chain specification is the standard motorcycle drive chain size, and the 14-tooth design provides good acceleration performance. This sprocket is the ideal replacement when the original shows signs of tooth wear, chipped teeth, or abnormal noise.

✨ Key Functions: Transmits power to rear wheel · Works with chain drive · Determines gear ratio · Wear resistant & impact resistant · Precision tooth profile

📐 Specifications

Product Name

428 14T Steel Front Sprocket

Engine Application

139FMB / 147FMD / 147FMF / 150FMG

Chain Size

428

Tooth Count

14 Teeth

Material

High-Strength Steel · Heat Treated

Position

Transmission Output Shaft

⚙️ Sprocket Tooth Count Performance Impact

📈 14-Tooth Front Sprocket

Better acceleration, strong low-end power, excellent hill climbing

✔ Ideal for city commuting
✔ Great for heavy loads and hills
✔ Moderate fuel consumption

📉 17T Front Sprocket

Higher top speed, better fuel economy at highway speeds

✔ Ideal for long-distance riding
✔ Better highway fuel economy
✔ Slightly reduced low-end acceleration

📌 Tooth Count Recommendation: The 14-tooth front sprocket provides better acceleration and hill climbing performance, ideal for city riding, heavy loads, or mountainous terrain. For higher top speed, consider a 17-tooth front sprocket.

🔧 Compatible Engine Models

This front sprocket fits the following engine models:

139FMB

147FMD

147FMF

150FMG

Engine Reference Information:

139FMB: 1P39FMB / 1P39QMB · 50cc-125cc universal engine
147FMD: 1P47FMD · 70cc-110cc engine
147FMF: 1P47FMF · 90cc-110cc engine
150FMG: 1P50FMG · 125cc-150cc engine

Note: This sprocket is designed for C100/universal countershaft spline specifications and uses 428 chain size.

🛵 Compatible Vehicles

Mopeds - Various 50cc-150cc moped models (underbones, scooters, etc.)
Cub Series - Honda Cub and clone models
Dirty Bikes - Small off-road motorcycles
ATVs - Small-engine quad bikes / kids ATVs
Other vehicles using 139FMB, 147FMD, 147FMF, 150FMG engines

📌 Compatibility Note: This front sprocket is suitable for the engine models listed above. Before installation, please verify your vehicle uses 428 chain and the countershaft spline is C100/universal type.

⚙️ Importance of Front Sprocket

🔗 Power Transmission

Transmits transmission output power to the rear wheel via the chain.

⚙️ Gear Ratio Adjustment

Changing front sprocket teeth adjusts acceleration and top speed characteristics.

🛡️ Wear Critical

The front sprocket has fewer teeth and spins faster, wearing faster than the rear sprocket.

🔧 Chain Compatibility

Precision tooth profile directly affects chain life and smooth power transfer.

⚠️ Front Sprocket Failure Symptoms: Drive system noise (clicking from chain area), jerky acceleration, chain jumping, worn teeth (hook-shaped), abnormal chain tension. If these occur, inspect and replace the front sprocket and chain.

⚠️ Common Failure Symptoms

Drive Noise: Rhythmic clicking or grinding from the chain area that changes with vehicle speed.
Jerky Acceleration: Power delivery feels uneven with shock during acceleration.
Chain Jumping: Chain runs unevenly on the sprocket, visible jumping.
Worn Teeth: Inspection reveals severely worn, hook-shaped, or pointed teeth.
Abnormal Chain Tension: Chain becomes loose quickly even after adjustment.
Broken Teeth: Severe cases may cause tooth breakage and power loss.

If you experience these symptoms, inspect the front sprocket and chain, and replace if necessary. For best results, replace the chain and rear sprocket simultaneously.

✨ Product Features

OEM Specifications: Manufactured to original tooth profile and dimensions for perfect chain engagement.
High-Strength Steel: Made from premium alloy steel with excellent strength and impact resistance.
Precision-Machined Teeth: Precision machining ensures accurate tooth profile for smooth engagement and low noise.
Heat Treated: Teeth are heat-hardened for superior wear resistance and long service life.
428 Chain Size: Standard motorcycle drive chain specification, widely compatible.
14-Tooth Design: Provides excellent acceleration performance, ideal for city riding and hill climbing.
Direct Replacement: Directly replaces worn or damaged original front sprocket without modification.

🔧 Installation Tip

1. Replacing the front sprocket requires removing the left engine sprocket cover; professional installation is recommended.
2. Clean the countershaft splines and sprocket mounting surface thoroughly before installation.
3. Inspect the countershaft splines for wear; have them repaired if damaged.
4. Align the sprocket with the locating tab or spline groove during installation.
5. Tighten the sprocket retaining nut or bolt to the specified torque.
6. It is recommended to replace the chain and rear sprocket simultaneously for optimal performance and longevity.
7. After installation, adjust chain tension to specification (typically 15-25mm free play).
8. Start the vehicle and check for abnormal noise; verify smooth chain operation.

⚠️ Important Notice: This is a C100 428 14-tooth steel front sprocket, suitable for Mopeds, Cubs, Dirty Bikes, ATVs, and vehicles using 139FMB, 147FMD, 147FMF, 150FMG engines.
Specification Confirmation: Please verify your vehicle uses 428 chain and the countershaft spline is C100/universal type. The 14-tooth design provides excellent acceleration; for higher top speed, consider 17T versions.
Installation Notes: Pay attention to sprocket orientation and torque specifications. It is recommended to replace the chain and rear sprocket simultaneously. Images are for reference only. The actual product may vary.
