Oil Strainer Cover

Brand: Mortch Motor
Product Code: MICF0JWV-011012-3000

Product Viewed: 855

Availability: In Stock

Weight: 0.06kg

0 reviews / Write a review

US$9.87

Shipping To：

More Quotes

CFMoto Oil Strainer Cover

Part Number: 0JWV-011012-3000

Product Type: Oil Strainer Cover | Engine Lubrication System Component

Material: Aluminum Alloy

Applicable Engines: 2V91W-F (850cc), 2V91Y-F (1000cc), 2V91W-K (800cc)

Genuine CFMoto oil strainer cover for sealing the oil strainer cavity, ensuring proper lubrication system operation

📋 Product Overview

This product is a genuine CFMoto oil strainer cover, part number 0JWV-011012-3000. This cover is installed on the bottom or side of the engine crankcase to seal the oil strainer cavity, protecting the strainer and ensuring smooth oil flow to the oil pump. Manufactured from high-strength aluminum alloy, offering excellent corrosion resistance, high-temperature performance, and structural strength for long-term reliable use.

Technical Features:

OEM Number: 0JWV-011012-3000
Material: High-strength aluminum alloy, corrosion resistant, heat resistant
Function: Seals oil strainer cavity
Mounting Location: Bottom or side of crankcase
Sealing Design: Used with O-ring or gasket

🔧 Genuine Quality Assurance: Manufactured strictly according to CFMoto original technical standards. Material and dimensional accuracy are identical to the OEM part, ensuring perfect match and sealing performance.

📐 Specifications

Part Number: 0JWV-011012-3000

Product Type: Oil Strainer Cover

Material: High-Strength Aluminum Alloy

Applicable Engine Series: 2V91W-F, 2V91Y-F, 2V91W-K

Displacement: 850cc, 1000cc, 800cc

🔧 Applicable Models Information

🏍️ 1000cc Series — 2V91Y-F Engine

ATV CF1000ATR-2 CForce 1000 TOURING 2V91Y-F
ATV CF1000ATR-2(GD) CForce 1000 TOURING 2V91Y-F
ATV CF1000ATR-2(HLG) CForce 1000 TOURING 2V91Y-F
ATV CF1000ATR-2(SS) CForce 1000 TOURING 2V91Y-F
ATV CF1000ATR-2A CForce 1000 OVERLAND 2V91Y-F
ATV CF1000ATR-2A(GD) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000ATR-2A(HLG) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000ATR-2A(SS) CForce 1000 2V91Y-F
ATV CF1000ATR-3 CForce 1000 MV 2V91Y-F
ATV CF1000ATR-3(GD) CForce 1000 MV 2V91Y-F
ATV CF1000ATR-3(SS) CForce 1000 MV 2V91Y-F
ATV CF1000ATR-3L CForce 1000 2V91Y-F
ATV CF1000ATR-3L(GD) CForce 1000 2V91Y-F
ATV CF1000ATR-3L(HLG) CForce 1000 2V91Y-F
ATV CF1000ATR-4L CForce 1000 2V91Y-F
ATV CF1000AU-2 CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2 CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2(AU) CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2(CA) CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2(RU) CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2(ST) CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2(US) CForce 1000 TOURING 2V91Y-F
ATV CF1000AZ-2A CForce 1000 OVERLAND 2V91Y-F
ATV CF1000AZ-2A(AU) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000AZ-2A(CA) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000AZ-2A(ST) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000AZ-2A(US) CForce 1000 OVERLAND 2V91Y-F
ATV CF1000AZ-3 CForce 1000 MV 2V91Y-F
ATV CF1000AZ-3(AU) CForce 1000 MV 2V91Y-F
ATV CF1000AZ-3(RU) CForce 1000 MV 2V91Y-F
ATV CF1000AZ-3(ST) CForce 1000 MV 2V91Y-F

🏍️ 850cc Series — 2V91W-F Engine

ATV CF800ATR-5 CForce 850 TOURING 2V91W-F
ATV CF800ATR-5(GD) CForce 850 TOURING 2V91W-F
ATV CF800ATR-5(HLG) CForce 850 TOURING 2V91W-F
ATV CF800ATR-5(SS) CForce 850 TOURING 2V91W-F
ATV CF800AU-3 CForce 850 TOURING 2V91W-F
ATV CF800AZ-3 CForce 800 TOURING/CForce 850 TOURING 2V91W-F
ATV CF800AZ-3(AU) CForce 800 TOURING 2V91W-F
ATV CF800AZ-3(CA) CForce 800 TOURING 2V91W-F
ATV CF800AZ-3(RU) CForce 800 HO 2V91W-F
ATV CF800AZ-3(ST) CForce 850 TOURING 2V91W-F
ATV CF800AZ-3(US) CForce 800 TOURING 2V91W-F

🏍️ 800cc Series — 2V91W-K Engine (UForce XL)

UTV CF800UTR-4 UForce 800 XL 2V91W-K
UTV CF800UU-4 UForce 800 XL 2V91W-F
UTV CF800UU-4(AU) UForce 800 XL 2V91W-F
UTV CF800UU-4(ST) UForce 800 XL 2V91W-F
UTV CF800UZ-4 UForce 800 2V91W-F
UTV CF800UZ-4(CA) UForce 800 XL 2V91W-F
UTV CF800UZ-4(US) UForce 800 XL 2V91W-F

📌 Compatibility Note: This oil strainer cover fits CFMoto models equipped with 2V91Y-F (1000cc), 2V91W-F (850cc), and 2V91W-K (800cc) engines, including CForce and UForce models. Minor differences may exist between different years or configurations. Please verify your original part number 0JWV-011012-3000 before purchasing, or contact customer service with your VIN/engine model for confirmation.

⚙️ Product Features

OEM Matching: Part number 0JWV-011012-3000 corresponds exactly to the CFMoto official parts system, ensuring direct replacement with no modifications required.
High-Strength Aluminum Alloy: Made of high-quality aluminum alloy, corrosion resistant, heat resistant, high structural strength, long service life.
Precise Dimensions: Accurate mounting holes and sealing surface dimensions ensure perfect fit with crankcase.
Reliable Sealing: Used with O-ring or gasket to ensure leak-free operation.
Lightweight: Aluminum construction is lightweight, contributing to overall vehicle weight reduction.
Strainer Protection: Effectively protects the oil strainer from external impact and debris.

📖 Installation Guide

Follow these steps to properly install the oil strainer cover and ensure proper lubrication system operation.

🔧 Pre-Installation Preparation

Ensure the engine is turned off and completely cooled down.
Prepare a drain pan, socket wrench, torque wrench, clean rags, and sealant (if required).
Check the O-ring or gasket condition — replace if aged or damaged.
It is recommended to have fresh engine oil ready for refilling after installation.

🔄 Step 1: Remove the Old Oil Strainer Cover

Place the vehicle on level ground. Remove the drain plug and drain the old oil into the pan.
Locate the oil strainer cover on the engine crankcase (bottom or side).
Using the appropriate socket wrench, remove the bolts securing the cover.
Carefully remove the old cover, noting that residual oil may be present.
Thoroughly clean the mounting surface with a clean rag, removing old gasket residue and debris.
Inspect the mounting surface for scratches or damage, and repair if necessary.

🧽 Step 2: Install the New Oil Strainer Cover

Remove the new cover (0JWV-011012-3000) from its packaging and check for any damage or casting defects.
Ensure the O-ring or gasket is in good condition and correctly seated in the cover's sealing groove.
Align the new cover with the mounting base, ensuring alignment pins or locating holes match.
Install the mounting bolts and tighten to factory torque specifications using a torque wrench (refer to your vehicle's service manual).
Do not overtighten, as this may damage the cover or mounting threads.

✅ Step 3: Post-Installation Check

Tighten the drain plug and refill with the recommended amount of fresh engine oil.
Start the engine and let it idle for 1-2 minutes. Inspect around the cover for any leaks.
Turn off the engine, wait a moment, and check the oil level on the dipstick. Top up if necessary.
Record the mileage and date of this service for future maintenance reference.

💡 Installation Key Points

Always clean the mounting surface thoroughly before installation to ensure no debris remains.
Check that the O-ring or gasket is in good condition — replace if necessary.
It is recommended to inspect the cover condition every time the oil pan is removed.
If you are not experienced with mechanical repairs, we recommend having this installed by a professional technician.

✅ Installation Tip: Clean the mounting surface before installation, check O-ring or gasket condition (recommended to replace with new). Align the cover with mounting holes, push into place by hand, tighten mounting bolts to specified torque. Check for leaks after installation.

⚠️ Important Note: This product is a CFMoto oil strainer cover, part number 0JWV-011012-3000, made of high-strength aluminum alloy. Compatible models are listed above. Different years or batches may have design variations. Please verify your original part number before purchasing. Images are for reference only, actual product may vary.
